Gospower GPEO-4KL1 pure sine wave solar inverter is a perfect design for home- installation with its compact size and quick setting. With a wide MPPT operating range of 85-450V, Gospower inverter is a good option for your household system.
Item No :
GPEO-4KL14kW Residential Off-Grid Single Phase Inverter Built-in MPPT 15A
IP54 Design
Pure Sine Wave
Built-in MPPT
BMS Communication
3 Years Warranty
Our Pure Sine Wave Inverter is combining functions of off-grid inverter, MPPT solar charge controller and isolated transformer, AC transfer from DC, and integrated with basic battery chargers which can be used to boost the battery from an AC power source to offer an uninterruptible power supply with a compact size.
The Gospower GPEO-4KL1 pure sine wave solar inverter is a top high quality low frequency power inverter, built for running your whole house (small home), Business, RV System, Trailer, or Boat Application. It is also perfect for your off grid system or an emergency backup supply.
| |
GPEO-4KL1 |
GPEO-6KL1 |
GPE0-12KL1 |
|
| PV (DC Input) |
Recommended max.PV input power | 4000W | 6000W | 12000W |
| Max.input voltage(Voc) | 500V | 500V | 500V | |
| MPPT operating voltage range | 85V-450V(@85V start up) | 85V-450V (@75V start up) | 85V-450V (@75V start up) | |
| Number of MPPT | 1 | 1 | 2 | |
| Max.number of input strings per MPPT | 1 | 1 | 1 | |
| Max.input current per MPPT | 15A | 27A | 27/27A | |
| Max.short-circuit current per MPPT | 18A | 35A | 35/35A | |
| Grid (AC Input) |
Max input power | 5000W | 11500W | 16000W |
| Max input current | 28A | 50A | 90A | |
| Rated grid voltage | 220/230/240Vac | 220/230/240Vac | 220/230/240Vac | |
| Rated grid frequency | 50/60Hz | 50/60Hz | 50/60Hz | |
| Acceptable range | 170-280Vac(For UPS); 90-280Vac(For Home Appliances) |
170-280Vac(For UPS); 90-280Vac(For Home Appliances) |
170-280Vac(For UPS); 90-280Vac(For Home Appliances) |
|
| Battery Parameters (Bidirection) |
Battery type | LiFePO4/Lead-acid | LiFePO4/Lead-acid | LiFePO4/Lead-acid |
| Battery voltage range | 20~30Vdc | 40~60Vdc | 40~60Vdc | |
| Rate Battery Voltage | 24Vdc | 48Vdc | 48Vdc | |
| Max.charge/discharge current | 120A/160A | 120A/130A | 210A/230A | |
| BMS communication mode | RS485 | RS485 | RS485 | |
| Back-up Output (AC Output) |
Rated output power | 4000W/4000VA | 6000W/6000VA | 12000W/12000VA(Twin output) |
| Rated output current | 18.2A | 27.3A | 54.5A | |
| Rated output voltage /Frequency | 220/230/240Vac 50/60Hz | 220/230/240Vac 50/60Hz | 220/230/240Vac 50/60Hz | |
| Parallel Capacity | _ | Max. 12 Units | Max. 12 Units | |
| Surge power | 8000VA 5s | 12000VA 5s | 24000VA 5s | |
| THDv(@linear load) | ＜3% | ＜3% | ＜3% | |
| Switching time | 10ms typical (For UPS) 20ms typical(For Home Appliances) | |||
| Efficiency | Peak efficiency | 95.00% | 98.00% | 98.00% |
| Max.MPPT efficiency | 99.90% | 99.90% | 99.90% | |
| Protection | Inner protection | √ Output short-circuit protection √ Output overvoltage protection | ||
| Surge protection | PV:Type III,AC:Type III | |||
| IP rating | IP54 | |||
| General Parameters |
Operating temperature range | -10℃~55℃ | ||
| Relative humidity range | 5%~95% | 5%~95% | 5%~95% | |
| Max.operating altitude | ＞2000m derating | ＞2000m derating | ＞2000m derating | |
| Standby self-consumption | ＜10W | ＜10W | ＜20W | |
| Installation type | Wall-mounted | Wall-mounted | Wall-mounted | |
| Cooling mode | Fan cooling | Fan cooling | Fan cooling | |
| Communication | RS232/RS485/Dry contact/WI-FI | RS232/RS485/Dry contact/WI-FI | RS232/RS485/Dry contact/WI-FI | |
| Display | LCD | LCD | LCD | |
| Mechanical Specification |
Inverter dimensions (L*W*H) (mm) | 444.7*346.6*120 | 444.7*346.6*120 | 630*535*125 |
| Net weight (kg) | 9.2 | 12.4 | 27 | |
| Shipping dimensions (L*W*H)(mm) | 560*465*240 | 560*465*240 | 745*650*240 | |
| Gross weight (kg) | 11.4 | 14.6 | 30 | |
| Warranty Period | 3 Years | |||
|
